Figure 7-2: Tamper Switch
7.3 Connections
Under the terminal cover, there are two terminal blocks:
 TB1 – Supply Connections
 TB2 – 2A Relay ALCS Connection
Figure 7-3: Terminal Blocks
Terminal Block 1 (TB1)
Supply Connections
Terminal Block 2 (TB2)
2A Relay ALCS
Connection
Tamper Switch
