13.3.3.3 BlkCtMx
The BlkCtMx menu item displays the TOU Block Counter Matrix. Pressing OK moves to the next
table displaying the next block of usage. There can be a maximum of four tables and eight rates
included in those tables.
For example, rows one and two of table one (Block One) would be represented as:
Similarly, rows one and two of table two (Block Two) would be represented as:
When in this menu, the UI buttons perform the following actions:
Left / Right
Scroll up or down the table. Wrapped.
OK
Move to next table. Wrapped.
Return
Returns to parent menu.
13.4 Security Menu Screens
The Main Security screen provides access to the:
 Set PIN menu, on which you can set a PIN or change an existing PIN.
 Remove an existing PIN.
13.4.1 Set PIN
If no PIN exists, on entering the Set PIN menu item, the screen will display the prompt
Using the left and right buttons, scroll through the digits 0-9 and press OK to select the digit. The
digits will be masked with an asterisk * symbol when selected. For example:
B
1
R
1
0
1
2
3
4
5
6
kWh
B
1
R
2
0
0
0
0
4
5
6
kWh
B
2
R
1
0
2
3
4
5
6
7
kWh
B
2
R
2
0
0
1
2
3
4
5
kWh
P
I
N
_
_
_
_
