EDMI ES-10B - Engineering Menu

ES-10B 4 Terminal Single Phase Residential Electricity
Meter - Product Guide
Copyright © 2019 EDMI Europe Ltd. All rights reserved
Version / Status: 1.1
Public
PAGE 45 OF 62
Return
Return to parent menu.
Left / Right
Next option
OK
1 second hold keeps the ALCS switch closed for a further 30min
Return
Return to parent menu.
Upon successful extension of the switch closure the display will show <Time> as the total duration
(start plus extend times) and the display will change to:
13.8 Engineering Menu
The Engineering menu enables installers to access information that should otherwise be
unavailable to the customer. When the meter is sealed, the Engineering menu cannot be
accessed. In order to access the menu, the terminal cover must be partially removed.
Note: Normal installation, commissioning, and operation of the meter does not require any access
to the Engineering menu.
13.8.1 Accessing the Engineering Menu
To access the Engineering menu, loosen the terminal cover enough to activate the tamper
detection switch.
Left / Right
Next option
OK
1 second hold keeps the ALCS switch closed for a further 45min
Return
Return to parent menu.
3
0
M
I
n
H
O
L
D
O
K
4
5
M
i
n
H
O
L
D
O
K
D
O
N
E
<
T
I
M
E
>
