ES-10B 4 Terminal Single Phase Residential Electricity
Meter - Product Guide
Copyright © 2019 EDMI Europe Ltd. All rights reserved
Version / Status: 1.1
Public
1 Introduction
The EDMI ES-10B is a single element, SMETS 2 compliant single phase direct connected
electricity meter with ALCS support that can be fitted with an ICHIS compliant Communications
Hub.
The EDMI ES-10B electricity meter and Communications Hub (if fitted) are intended for use in CAT
III 300V / 4000VAC impulse rated installations. This means that they are suitable for use in
locations on conductors that have up to 300V phase to ground and can withstand transient
impulses up to 4000VAC.
1.1 Safety Precautions
Only qualified electricity meter installers should install this equipment.
To prevent incidents of electric shock, explosion, or arc flash hazards, follow safe electrical work
practices:
Handle any parts indicated by and warning labels with caution. These symbols show
where live circuits or high voltage connections are present.
The internal relay of the meter is not an isolator. Therefore, never assume that the meter is
isolated even if the relay is open.
Failure to follow safe electrical working practices may lead to personal injury, damage to
electrical equipment and other property; serious injury or death in the worst scenario.
1.2 Meter Warning Symbols
This symbol indicates the presence of high voltage and risk of electric shock hazards.
The meter must be isolated or disconnected from hazardous live voltage before access!
WARNING: To avoid risk of electric shock, do not touch these parts when the
meter is live.
This symbol is placed to make people aware of possible dangers or hazard ahead in the
process of installing the meter. It indicates a need to consult to instructions provided in
this manual.
WARNING: A potential risk exists if the operating instructions are not followed.
