(For example)
To activate emergency credit, press and hold the Return button.
If the meter balance has fallen below £0, and there is emergency credit available, the procedure for
applying credit is the same as above.
However, if there is no emergency credit available, the Home screen will display:
Indicating that there is no credit available and the minimum top up required to re-enable supply. In
this event, follow the procedure described in section 14 Top Up Pay As You Go Credit.
16 Communications Hub
Normally, a Communications Hub will be fitted to the top of the meter after installation. The
Communications Hub allows the various elements of a Smart Metering System to communicate
with each other and to the supplier (via the Communications Service Provider).
Only Communications Hubs that follow the ICHIS standard are compatible with the ES-10B
(previous hubs used with the Mk7B are not compatible). Figure 16-1 shows a meter with an
intimate connection to an Arqiva Communications Hub.
For detailed installation instructions, please refer to the Communications Hub installation
documentation.
B
A
L
N
C
1.
4
5
£
N
O
C
R
E
D
I
T
M
I
N
T
P
1
0.
2
0
£
