Upon successful opening of the switch, the display will change to
Left / Right
No effect.
OK
1 second hold initiates ALCS switch state to normal operation as per configured ALCS calendar..
Return
Return to parent menu.
13.7.3 Extnd
To extend the boost function only if a Boost Period is active,
The possible selections available will depend upon the amount of time that the boost function was
activated for, so that the total time cannot exceed one hour.
For example if the boost was activated for 1 hour, then it is not possible to extend this time – and
no option will be available for selection, the options are detailed in the table below.
Activation Time Period
Extension Time Period Options
1 hour
None
45mins
15mins
30mins
15mins, 30mins
15mins
15mins, 30mins, 45mins
0
None
It should use this information to populate the submenu labels, the following submenu should be
available on the UI.
On selection of an above submenu, the LCD will display:
Left / Right
Next option
OK
1 second hold keeps the ALCS switch closed for a further 15min
D
O
N
E
1
5
M
i
n
H
O
L
D
O
K
