EDMI ES-10B - Page 33

ES-10B 4 Terminal Single Phase Residential Electricity
Meter - Product Guide
Copyright © 2019 EDMI Europe Ltd. All rights reserved
Version / Status: 1.1
Public
PAGE 33 OF 62
(Full message string “0123456789101”)
When in this menu, the UI buttons perform the following actions:
Left / Right
No effect.
OK
No effect.
Return
Return to parent menu.
13.5.6 Logs
The Logs menu provides access to the:
 Event Log
 Power Log
 ALCS Log
13.5.6.1 Event Log
Note: Event and message codes are defined in GBCS Table 16.4.
The Events menu displays the meter’s Event Log. A maximum of 100 events are displayed, the
most recent event being 1. The top row of the screen shows the event number (1-100) and the
bottom row shows event code the timestamp information.
Use the left/right buttons to scroll up and down the list of events and press the OK button to switch
between the Event Code and the Timestamp display (every two seconds, the Timestamp display
cycles between the date and time display).
For example:
This indicates that the first message in the Event Log (001) is GBCS Event Code 8254.234.
Pressing OK will display:
This shows that Event 001 occurred at 23:01:15 on 01.01.15. The display will cycle between the
time and date every two seconds.
When in this menu the UI buttons perform the following actions:
E
X
P
R
T
0
1
2
3
4
5
6
0
0
1
8
2
5
4.
2
3
4
0
0
1
0
1.
0
1.
1
5
0
0
1
2
3:
0
1:
1
5
