Chapter 1: Introduction
P/N 3102309-EN • REV 001 • ISS 18JUL19 11
Using the touch screen
The EST4 LCD touch screen provides interactive operator controls.
• Tap an event message on the information screen to display message details.
• Tap buttons on the Action bar and Command bars to open screens where you can apply system operations
and system functions. See Table 7 and Table 8 on page 13 for details.
• Tap scroll arrows to scroll through system buttons on bars and event messages on the information screen.
• Drag scroll bars to scroll through event messages on the information screen.
List bar
The List bar (Figure 3 on page 7) contains buttons for selecting which event messages you want to display on the
screen. The List bar is only available when the system is off-normal screen.
Up to ten lists may be available based on your control unit configuration and market setting. Tap the left or right
scroll button to view buttons that may be hidden.
Table 6: List bar button descriptions
Minimum fire
privilege level
Description
0 Displays the Call In event list, which shows firefighter telephone call events stored in the
list, in the order in which they were received.
View an event’s Details Report by tapping the event, and then the details button
⚲. Print
the Details Report by tapping the print button
.
0 Displays the Control Requests event list, which shows a list of control requests and
whether granted or denied, in the order in which they were received.
View an event’s Details Report by tapping the event, and then the details button ⚲. Print
the Details Report by tapping the print button
.
0 Displays the Alarm event list, which shows alarm events stored in the list, in the order in
which they were received.
View an event’s Details Report by tapping the event, and then the details button
⚲. Print
the Details Report by tapping the print button
.
0 Displays the Emergency event list, which shows emergency events stored in the list, in
the order in which they were received.
View an event’s Details Report by tapping the event, and then the details button ⚲. Print
the Details Report by tapping the print button
.
visory 0 Displays the Supervisory event list, which shows supervisory events stored in the list, in
the order in which they were received.
View an event’s Details Report by tapping the event, and then the details button
⚲. Print
the Details Report by tapping the print button
.
0
Displays the Building event list, which shows building events stored in the list in the order,
in which they were received.
View an event’s Details Report by tapping the event, and then the details button
⚲. Print
the Details Report by tapping the print button
.
