Chapter 1: Introduction
12 P/N 3102309-EN • REV 001 • ISS 18JUL19
List
Minimum fire
privilege level
Description
Disable
0 Displays the Disabled event list, which shows disabled events stored in the list, in the
order in which they were received.
View an event’s Details Report by tapping the event, and then the details button
⚲. Print
the Details Report by tapping the print button
⎙
.
Trouble
0 Displays the Trouble event list, which shows trouble events stored in the list in the order,
in which they were received.
View an event’s Details Report by tapping the event, and then the details button
⚲. Print
the Details Report by tapping the P print button
⎙
.
Ground
Fault 0 Displays the Ground
Fault event list, which shows ground fault events stored in the list, in
the order in which they were received.
View an event’s Details Report by tapping the event, and then the details button ⚲. Print
the Details Report by tapping the print button
⎙
.
Other
0
Displays the Other event list, which shows ancillary events stored in the list in the order in
which they were received.
View an event’s Details Report by tapping the event, and then the details button
⚲. Print
the Details Report by tapping the print button
⎙
.
Action bar
The Action bar (Figure 3 on page 7) contains buttons for selecting system commands. Tapping action buttons
opens system information and interactive screens, and command buttons that are used to apply system
operations. The Action bar is available whether the system is normal or off normal.
The LCD screen displays up to four action buttons at a time. Tap the left or right scroll button to view buttons that
may be hidden.
Table 7: Action bar button descriptions
Action button
Minimum fire
privilege level
Description
System
Info 0 Displays the System information screen, and launches the Command bar that provides
several system operation command buttons.
When signed in as fire privilege level 1 to 3 additional command system operation
buttons appear.
Project Tree
0 Displays the project tree. Use the vertical scroll bar to view hidden sections of the
expanded tree.
• Recent Site Locations: Shows up to 10 locations that the operator has viewed.
• Top level: Expanding the top level of the project tree shows expandable nodes and
branches that can hold hardware, operator, and communication devices.
Tapping a device on the tree, displays its Device details report.
For certain devices, the Command bar launches. The command buttons that appear are
dependent on the fire privilege level of the user.
Sign In
0 Displays a keypad for entering your 7-digit PIN to access to user privileges. The first
three digits of the PIN are your user ID followed by a 4-digit PIN.
Holidays
0 Displays the Holidays List screen.
Users
0 Displays the Users List screen.
