Edwards EST4 - Command Bar

Chapter 1: Introduction
P/N 3102309-EN • REV 001 • ISS 18JUL19 13
Action button
Minimum fire
privilege level
Description
Request control
0 Activates a request to take control of the system and displays the Requests event
indicator/counter, sounds the operator alert signal, and displays the Control Request List
button.
Tapping the Control Requests list button allows you to grant or deny a request. See
“Request Grant Deny logics” on page 55.
Alternate
language
(Example:
Española
or
English)
0 Switches the names on LCD screen buttons, lists, indicators, and the text in primary
event message to the 4-CU configured alternate language.
Note: The alternate language button only appears when the feature is programmed by
the system administrator.
Command bar
The Command bar (Figure 3 on page 7) appears when you tap certain action buttons or items on the LCD screen.
For example, if you tap the System Info button, the Command bar appears containing several buttons that include
allowing you to enable and disable devices and zones, activate and restore switch outputs, and view system
reports.
The LCD screen displays up to four command buttons at a time. Tap the left or right scroll button to view buttons
that may be hidden.
Table 8: Command bar button descriptions
Action button
Command button Minimum fire
privilege level
Description
System Info
System Info 0 System information report. Lists the control unit firmware version,
SDU and hardware configurations, and licensing information.
Status 0 Status (all) report. Lists active events and disabled points from the
selected node.
Status Disabled 0 Status (disabled) report. Lists all addressable points
that are in the
disabled state.
Status Test 0 Status (test) report. Lists off-normal devices under test.
History 0 History – All Dates report. Lists the last 20,000 events and
operator commands processed by the selected node.
History Alarm 0 History –
All Dates, Alarm report. Lists the event name, time, date,
and location text for all alarm events.
History Trouble 0 History – All Dates, Trouble report. Lists the event name, time,
date, and location text for all trouble events.
History Supervisory 0 History –
All Dates, Supervisory report. Lists the event name, time,
date, and location text for all supervisory events.
Maintenance (all) 0 Maintenance report. Lists the %Dirty value for all of the detectors
on a signaling line circuit for the selected node. For CO detectors
the report includes CO Life Left Months or CO DAY Running. The
report includes each detector’s model type, primary and alternate
alarm sensitivity values, and, if programmed, a location
description.
Maintenance Dirty 0 Maintenance (dirty) report. Lists all addressable smoke detectors
that have a %Dirty value 20% and greater. A smoke detector that
is more than 20% dirty should be noted for possible cleaning or
replacing.
