EE Bright Box User Manual
11
username and password have been entered
incorrectly.
Off
The router can’t detect a broadband signal.
If you are using the EE Fibre broadband service
check that the Ethernet connection between the
WAN port on the Bright Box and LAN1 port on the
Fibre modem is connected and the modem is
powered on.
Data
Flashing
Traffic is being sent or received between the
computer and router, or the router and the
internet
Off
For ADSL broadband that means that no data is
currently being sent or received from the router.
If you are using the EE Fibre broadband service,
this light will always be off, and this is normal.
Wireless
On
The wireless access point is enabled.
Flashing
Data is being sent via the wireless link.
Off
Wireless has been disabled.
Intelligent
Wireless/
WPS
On
A successful WPS connection has been made.
Fast
Flashing
The WPS button has been pressed - the router is
capable of setting up a WPS connection.
Slow
Flashing
The router is searching for a new wireless
channel as part of the Intelligent wireless
process.
Off
Default behaviour – WPS or Intelligent wireless
aren’t currently in progress.
Ethernet 1-
4 (ADSL
Broadband)
On
Ethernet connection has been established with
the indicated port.
Flashing
The Ethernet connection is sending/receiving
data.
Off
There is no Ethernet connection on the port.
Ethernet 4
(Fibre
Broadband)
On
A connection has been established between the
Bright Box and the Fibre modem.
Flashing
Data is being sent between the Bright Box and
the Fibre modem.
Off
The Ethernet connection between the Bright Box
and the Fibre modem has been disconnected or
the modem is powered off.
Check that the Ethernet connection between the
WAN port on the Bright Box and LAN1 port on the
Fibre modem is connected and the modem is
powered on.
BACK PANEL VIEW
On the back panel of the Bright Box you will find the following ports, sockets and buttons:
