SERVICING THE E-43A WITH FURNITURE 125
6 Use the handle on the stability bracket to lift the rear of the E-43A. Slide the E-43A all the
way forward into the stand. Lock the E-43A into place with the two thumbscrews that you
removed earlier.
7 Connect the two monitor cables (power and video):
Power to the back of the monitor and to the wall outlet
Video to the back of the monitor and to the back of the E-43A
Stability bracket (lock into
place with two thumbscrews)
Video cable
Power cable
