REPLACING PARTS 83
TO REPLACE THE SWITCH BANK ASSEMBLY
1 If it is not already attached, attach the DVD drive to the switch bank assembly
(see page 85).
2 Install the switch bank assembly in the component sled (see Figure 33).
NOTE: If you are replacing the switch bank assembly with a new one, discard the cable
extensions that may be provided with the new switch bank assembly.
• Starting with the cables, insert the switch bank assembly through the opening in the front
of the component sled. Be sure to fold the EMI gasket under and through the opening
when inserting the assembly.
• Replace the three screws that secure the switch bank assembly to the component sled.
3 Install the component sled in the chassis (see Figure 32).
• Route the cables of the switch bank assembly in through the chassis so that the cables are
within reach of their connectors on the motherboard.
• Slide the sled into the front of the chassis until the guide latches click into place.
NOTE: Be careful not to damage the EMI gasket around the slot in the chassis when installing
the component sled.
4 Connect the following cables (see Figure on page 57 for the location of connectors on the
motherboard):
• Power and data combination cable
• DVD data cable
• Power button cable
• Reset button cable
• Speaker cable
• Front panel USB port cables
5 Install the ferrite around the two front USB port cables near the motherboard.
Use the ferrite that you removed earlier. Place the ferrite around both cables in between the
two preinstalled tie-wraps, and snap the edges of the ferrite closed.
6 Secure the cables with the cable clamp(s) inside the chassis.
7 Reassemble the E-43A and verify its functionality (see page 86).
