Chapter 1 Introduction
Resolution Scan
*1
Vertical
Scan
Frequency
Version 1.1
*2
Version 1.2,
Version 1.2 /
YUV
*2
YCbCr
4:4:4
YCbCr
4:2:2
RGB
4:4:4
3840 x 2160
*3
P 24.000 Hz √ √ 10 / 8 bit 10 / 8 bit 10 / 8 bit
3840 x 2160
*3
P 24.989 Hz √ √ 10 / 8 bit 10 / 8 bit 10 / 8 bit
3840 x 2160
*3
P 25.000 Hz √ √ 10 / 8 bit 10 / 8 bit 10 / 8 bit
3840 x 2160
*3
P 29.970 Hz √ √ 10 / 8 bit 10 / 8 bit 10 / 8 bit
3840 x 2160
*3
P 29.981 Hz √ √ 10 / 8 bit 10 / 8 bit 10 / 8 bit
3840 x 2160
*3
P 30.000 Hz √ √ 10 / 8 bit 10 / 8 bit 10 / 8 bit
3840 x 2160
*3
P 50.000 Hz - √ 8 bit 8 bit 8 bit
3840 x 2160
*3
P 59.940 Hz - √ 8 bit 8 bit 8 bit
3840 x 2160
*3
P 59.997 Hz - √ 10 / 8 bit 10 / 8 bit 10 / 8 bit
3840 x 2160
*3
P 60.000 Hz - √ 8 bit 8 bit 8 bit
*1 P: Progressive, I: Interlace
*2 “Signal Format” (page 35) must be set.
*3 Recommended resolution
●
HDMI
Resolution Scan
*1
Vertical
Scan
Frequency
4K 30Hz
*2
4K 60Hz,
4K 60Hz /
YUV
*2
YCbCr
4:4:4
YCbCr
4:2:2
YCbCr
4:2:0
RGB
4:4:4
640 x 480 P 59.940 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
640 x 480 P 60.000 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
720 x 400 P 70.087 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
720 x 480 P 59.940 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
720 x 480 I 59.940 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
720 x 480 P 59.941 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
720 x 480 P 60.000 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
720 x 480 I 60.000 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
720 x 576 P 50.000 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
720 x 576 I 50.000 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
800 x 600 P 60.317 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
1024 x 768 P 60.004 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
1280 x 720 P 50.000 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
1280 x 720 P 59.940 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
1280 x 720 P 60.000 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
1280 x 960 P 60.000 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
1280 x 1024 P 60.020 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
1600 x 1200 P 60.000 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
