Eizo ColorEdge CS2740 User Manual

30
Chapter 4 Advanced Adjustments/Settings
●
Preferences
The monitor's settings can be congured to suit the usage environment or personal preference.
Function Settings Description
Menu Rotation 0°
90°
This function allows you to change the orientation of the
Setting menu to align with the installation orientation.
Note
• When using the monitor screen in a portrait position, the
graphics board supporting portrait display is required.
When placing the monitor in a portrait position, settings
of your graphics board need to be changed. Refer to the
User's Manual of the graphics board for details.
• When using the monitor in a portrait position, rotate the
monitor after pulling up the screen to the uppermost
position of the stand and setting the screen tilted upward.
Power Save On
O󰀨
This function allows you to set the monitor to the power
saving mode, depending on the state of an external device
connected to it.
The monitor changes to power saving mode about 15
seconds after signal input ceases to be detected. When the
monitor has shifted to power saving mode, images are not
displayed on the screen.
• Exiting power saving mode
- If the monitor receives input, it automatically exits
power saving mode and returns to the normal display
mode.
Note
• At the time of shifting to power saving mode, a message
that indicates the transition is displayed 5 seconds in
advance.
• When you are not using the monitor, turn o󰀨 the main
power switch to cut down on power consumption.
• When the monitor is in power saving mode, devices
connected to the USB downstream port will still work.
Therefore, power consumption of the monitor varies
depending on the connected devices, even in the power
saving mode.

Eizo ColorEdge CS2740 Specifications

General

Pixel pitch	0.155 x 0.155 mm
Screen shape	Flat
Pixel density	164 ppi
Response time	10 ms
Display diagonal	26.9 \
Adobe RGB coverage	99 %
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	- Hz
Viewable size, vertical	2160 mm
Contrast ratio (typical)	1000:1
Display number of colors	1.07 billion colors
Display diagonal (metric)	68.4 cm
Viewable size, horizontal	596.2 mm
Digital vertical frequency	23 - 61 Hz
Digital horizontal frequency	25 - 137 kHz
Display brightness (typical)	350 cd/m²
Certification	CB, CE, TUV/GS, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, RCM, EAC, RoHS, WEEE, TUV/Ergonomics
Product color	Black
Market positioning	Graphics design
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	168 W
Power consumption (typical)	36 W
Power consumption (PowerSave)	1 W
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-B, USB Type-C
Number of upstream ports	2
USB Power Delivery up to	60 W
USB Type-A downstream ports quantity	4
Number of USB Type-B upstream ports quantity	1
Cables included	AC, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	265 mm
Width (with stand)	638 mm
Height (with stand)	404.1 mm
Weight (with stand)	10300 g
Depth (without stand)	75 mm
Height (without stand)	378.2 mm
Weight (without stand)	6700 g
