Chapter 1 Introduction
Resolution Scan
*1
Vertical
Scan
Frequency
4K 30Hz
*2
4K 60Hz,
4K 60Hz /
YUV
*2
YCbCr
4:4:4
YCbCr
4:2:2
YCbCr
4:2:0
RGB
4:4:4
2560 x 1440 P 59.951 Hz √ - 8 bit
12 / 10 / 8
bit
- 8 bit
2560 x 1600 P 59.972 Hz √ - 8 bit
12 / 10 / 8
bit
- 8 bit
3840 x 2160
*3
P 23.976 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
3840 x 2160
*3
P 24.000 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
3840 x 2160
*3
P 25.000 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
3840 x 2160
*3
P 29.970 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
3840 x 2160
*3
P 30.000 Hz √ √
12 / 10 / 8
bit
12 / 10 / 8
bit
-
12 / 10 / 8
bit
3840 x 2160
*3
P 50.000 Hz - √ 8 bit
12 / 10 / 8
bit
12 / 10 / 8
bit
8 bit
3840 x 2160
*3
P 59.940 Hz - √ 8 bit
12 / 10 / 8
bit
12 / 10 / 8
bit
8 bit
3840 x 2160
*3
P 60.000 Hz - √ 8 bit
12 / 10 / 8
bit
12 / 10 / 8
bit
8 bit
*1 P: Progressive, I: Interlace
*2 “Signal Format” (page 35) must be set.
*3 Recommended resolution
●
USB Type-C
Resolution Scan
*1
Vertical
Scan
Frequency
4K 30Hz /
USB3.1
*2
4K 60Hz /
USB2.0,
4K 60Hz /
USB2.0 / YUV
*2
YCbCr
4:4:4
YCbCr
4:2:2
640 x 480 P 59.940 Hz √ √ 10 / 8 bit 10 / 8 bit
640 x 480 P 60.000 Hz √ √ 10 / 8 bit 10 / 8 bit
720 x 400 P 70.087 Hz √ √ 10 / 8 bit 10 / 8 bit
720 x 480 P 59.940 Hz √ √ 10 / 8 bit 10 / 8 bit
720 x 480 P 59.941 Hz √ √ 10 / 8 bit 10 / 8 bit
720 x 480 P 60.000 Hz √ √ 10 / 8 bit 10 / 8 bit
720 x 576 P 50.000 Hz √ √ 10 / 8 bit 10 / 8 bit
800 x 600 P 60.317 Hz √ √ 10 / 8 bit 10 / 8 bit
1024 x 768 P 60.004 Hz √ √ 10 / 8 bit 10 / 8 bit
1280 x 720 P 50.000 Hz √ √ 10 / 8 bit 10 / 8 bit
1280 x 720 P 59.940 Hz √ √ 10 / 8 bit 10 / 8 bit
1280 x 720 P 60.000 Hz √ √ 10 / 8 bit 10 / 8 bit
1280 x 960 P 60.000 Hz √ √ 10 / 8 bit 10 / 8 bit
1280 x 1024 P 60.020 Hz √ √ 10 / 8 bit 10 / 8 bit
1600 x 1200 P 60.000 Hz √ √ 10 / 8 bit 10 / 8 bit
1680 x 1050 P 59.883 Hz √ √ 10 / 8 bit 10 / 8 bit
1680 x 1050 P 59.954 Hz √ √ 10 / 8 bit 10 / 8 bit
1920 x 1080 P 23.976 Hz √ √ 10 / 8 bit 10 / 8 bit
1920 x 1080 P 24.000 Hz √ √ 10 / 8 bit 10 / 8 bit
1920 x 1080 P 25.000 Hz √ √ 10 / 8 bit 10 / 8 bit
1920 x 1080 P 29.970 Hz √ √ 10 / 8 bit 10 / 8 bit
1920 x 1080 P 30.000 Hz √ √ 10 / 8 bit 10 / 8 bit
1920 x 1080 P 50.000 Hz √ √ 10 / 8 bit 10 / 8 bit
