Safety notes
2.1 General safety notes
SCD 19102 / SMD 19102
Instruction Manual, 10/2011, A5E01588521A-004
11
CAUTION
Improper installation may result in extensive damage to property.
Installation must be carried out by specialists.
1. To avoid danger for patients and users, connect your electrical system in accordance
with the safety requirements of EN 60601-1-1 (IEC 60601-1-1) "Safety requirements for
medical electrical systems".
In order to guarantee that the housing discharge current in the event of a first fault does
not exceed 500 µA, the display must be connected to an additional PE connection. The
bracket of the display's support mechanism has its own grounding (PE conductor). This
grounding together with the PE conductor of the display means that the housing
discharge current always remains less than 500 µA, even in the event of a first fault. The
PE conductors of the display and of the separate PC are considered as a first fault
event.
2. Use appropriate measures to ensure that the leakage currents in particular remain
below the necessary limits:
Appropriate measures include:
– Separators for signal input or signal output unit
– Use of a safety isolating transformer
– Use of the additional protective conductor terminal
3. Device and patient must never be touched simultaneously.
4. It must be specifically mentioned that the display is only suitable for a patient
environment, but not for contact with a patient.
5. Only use the video lines specified by the manufacturer for installation.
The serial interface cable must have a female Sub-D connector at the computer end.
6. Use power cables with PE contacts. Only plug the device into sockets with protective
grounding.
7. For certain applications, the video earth can be connected separately to the protective
earth via the additional PE connection in the plug panel.
Observe EN 60601-1-1 (IEC 60601-1-1).
8. Close the connection panel using the cover provided, and secure with the screws.
9. Note for users:
The closed connection panel may only be opened by trained and qualified personnel.
10. Servicing information:
If housing parts have to be removed for servicing, this must not be carried out in the
presence of the patient or user. Only connect displays with a VESA connection on the
rear panel to the power supply when the VESA plate is screwed on.
11. Important:
Note that displays can fail and that the image p
roperties such as brightness, contrast or
color location can change with time.
Please ensure that all steps are taken to avoid injuries or incorrect diagnoses. If your
application or local regulations require calibration, EIZO offers the optional QA software
"SMfit Total Care" to facilitate quality control and review activities. Observe all regulations
of the country in which the display is used.
