SCD 19102 / SMD 19102
Instruction Manual, 10/2011, A5E01588521A-004
23
Connecting
6
6.1 General connection information
CAUTION
All information and warnings related to this product must be observed to ensure danger-
free operation.
CAUTION
Changes to device
• Device settings may only be adjusted by trained service personnel; otherwise, the
warranty is void.
• Do not make any changes to the device without prior approval from the manufacturer.
The display is designed for individual connection to a graphics card with a power supply of
110 or 240 V (TN-S system with PE conductor).
CAUTION
Observe shielding measures
Please observe all local EMC guidelines pertaining to shielding. Ignoring such requirements
could allow signals to interfere with the proper operation of the display.
To guarantee perfect image reproduction, the following instructions should be observed:
• Only shielded cables are permitted for all signal connections.
• Screw tight or lock all plug-in connections.
• Signal and power cables must not be routed through the same duct.
• The display must not share a power supply with motors or valves (interference peaks!).
