Technical specifications
11.5 Control and connection elements
SCD 19102 / SMD 19102
92 Instruction Manual, 10/2011, A5E01588521A-004
11.5 Control and connection elements
Front
• Four buttons for OSD menu
• Operation LED
Rear side
• 1x power connection socket
• 1x DVI socket
• 1x 15-pin 3-row Sub-D socket
• 3x BNC sockets (SMD series only)
• 1x BNC socket
• 1x 4-pin mini-DIN socket
• 2x RS 232 sockets (RJ11)
• Voltage source for connection of external
devices (5 V/1 A)
• 2x 75 Ω/10 kΩ switch loop for H and V
Rear panel (accessible without detaching
connector panel cover)
• 1x power switch
• 1x RS 232 socket (6-pin mini-DIN socket)
11.6 Mechanical design
Housing components ABS
Protective glass For SCD / SMD 19102 CP only:
Safety glass, non-reflective both sides
Visible screen area Approx. 376 x 301 mm
Ventilation openings In rear panel
Degree of protection
• IP20 in accordance with DIN 40050
• IP22 at front only for SCD / SMD 19102 CP
Connector panel On rear panel, under cover
Weight in kg
• SCD / SMD 19102 C (without stand)
6.4 kg (± 0.3 kg)
• SCD / SMD 19102 CP (without stand, with
front pane)
7.0 kg (± 0.3 kg)
• SCD / SMD 19102 D (without stand)
11.4 kg (± 0.3 kg)
Dimensions (W x H x D) in mm
• SCD / SMD 19102 C (without stand)
422.5 x 348.5 x 95
• SCD / SMD 19102 CP (without stand, with
front pane)
422.5 x 348.5 x 95
• SCD / SMD 19102 D (without stand)
314 x 348.4 ... 546.5 x 279 *
* Corresponds to a possible height adjustment of 100 mm.
