Commissioning
7.3 Description of OSD menu
SCD 19102 / SMD 19102
48 Instruction Manual, 10/2011, A5E01588521A-004
Main menu Function Adjustment/range Description
OSD lock/hotkey Hotkey brightness / contrast
Hotkey backlight
Hotkey select source
Default: OSD available
Selection of different OSD
lock/hotkey settings:
• Hotkey brightness /
contrast:
The OSD menu is locked
and can only be unlocked
using a specific key
combination.
Only the brightness and
contrast can be changed
by any user with the OSD
keys without the need for
a key combination.
• Hotkey backlight:
The OSD menu is locked
and can only be unlocked
using a specific key
combination.
Only the backlight can be
changed by any user with
the OSD keys without the
need for a key
combination.
•
Hotkey select source:
The OSD menu is locked
and can only be unlocked
using a specific key
combination.
Only the source can be
changed by any user with
the OSD keys without the
need for a key
combination.
Note:
See "Lock OSD menu"
(Page 60)
Hotkey for PIP activation Active
Inactive
Default: Inactive
Activating and deactivating
the PIP window with button 4
on the front
If "Active" is selected, the
PIP window can be opened
or closed with the saved
settings using button 4 on
the front without opening the
OSD menu.
