13 - FAILURE TREE ANALYSIS
13.1 - ALARM CODE
To identify on which place a failure occurred, the first value shows the failure place, described at following
schematic:
Fxxx
F
x
x
x
Failure code
1 =
Oven PB failure
2 =
Oven User Interface failure
3 =
4 =
5 =
6 =
7 =
Hob failure
8 =
9 =
General failure
0 =
F =
Failure
Cx→
for customer errors / failures
EXAMPLE:
In the case of PT500 sensor, temperature too high detected from the card the system indicates the error
code F5 but is displayed on the user interface with F105 where the number "1" indicates the place where the
error occurred, in this case "1" is on the Power board Oven.
NOTE : Some user interfaces (e.g. Avantgarde) indicate the alarms or the warnings during the factory test.
