Electrolux OVC3000 - Block Diagram

Technical Support - BSP 7/47 599 73 09-98 Rev. 02
3 - BLOCK DIAGRAM
In Figure 1 shows the general block diagram of the use of the power board OVC3000.
Fig. 1
µ P
SENSOR
(PT500 oven
sensor)
LOADS
(Heating
elements,
fans etc.)
OVC3000 POWER BOARD
DISPLAY
BUZZER
µ P
USER INTERFACE
DOOR
LOCK
SENSOR
(Meat probe)
FPM FOOD
PROBE
MODULE
LOADS
ADDITIONAL
(Steam generator
etc.)
Bus for HOB (MACS)
/ SERVICE (Optional)
