1 - INTRODUCTION
1.1 - PURPOSE OF THIS MANUAL
The purpose of this Manual is to provide information of new Ovens Power board OVC3000.
1.2 - WARNINGS
 All work with open appliances must be done with the mains supply
disconnected.
 The intervention on electrical equipment should only be performed by
qualified personnel.
 Before an operation in a device, check the efficiency of the system housing
through means of appropriate equipment. As an example, refer to the
indications described / illustrated in the portal Electrolux Learning Gateway
(http://electrolux.edvantage.net).
After intervention, verify that the conditions have been restored to the
safety switch apparatus, as just leaving the assembly line.
 In the case of manipulation / replacement of the PCB, use the ESD kit (Code
405 50 63-95/4) to prevent electrostatic discharge damage the circuit board
see SB No. 599 72 08-09
1.3 - ABBREVIATIONS, ACRONYMS, DEFINITIONS
AD
Analogical Digital
APD
All Pole Disconnection relay
FP
Food Probe
FPM
Food Probe Module
HC
Hob controller power board
HUI
Hob User Interface
HXOUI
Hexagon Oven User Interface
HXPM
Hexagon Power module
OC
Oven controller power board
OVF
Oven Function
OUI
Oven User Interface
PWM
Pulse width modulation
SB
Smart Board
SPD
Single pole disconnection relay
SPI
Serial Peripheral Interface
ToD
Time of day (or OFF_STATE, depends on OUI)
VCU
“Vision Control Updated” (OUI type)
