Electrolux OVC3000 - Legend of Circuit Diagram

Technical Support - BSP 42/47 599 73 09-98 Rev. 02
14.4 - LEGEND OF CIRCUIT DIAGRAM
Reference
Description
Reference
Description
a1
switch 7-step front left
h9
lamp overheating
a2
switch 7-step rear left
h10
analog timer
a3
switch 7-step rear right
h11
electronic timer
a4
switch 7-step front right
h12
6-push electronic timer
a7
heating mode selector main oven
h20
timer primary code hob
a7t (a7.1)
heating mode selector top oven
h30
residual lamp
a8
LTC (Low Temp. Cooking) switch
h40
display board
a15
touch electronic switch warning zone
h52
display oven
a31
energy regulator front left
K
clutch
a32
energy regulator rear left
K1
relay
a33
energy regulator rear right
k1
LTC (Low Temp. Cooking) relay
a34
energy regulator front right
KS
switch child safety
a61
touch electronic switch front left
KS1
rotary hob plate front left
a62
touch electronic switch rear left
KS2
rotary hob plate rear left
a73
touch electronic switch rear right
KS3
rotary hob plate rear right
a84
touch electronic switch front right
KS4
rotary hob plate front right
A1
actuator exhaust
M1
hob connector 14-pole 1+2
A2
actuator desteam
M2
hob connector 14-pole 3+4
b3
socket meat probe
M3
connector 11-pole
BOF
mode selector function
M4
connector 7-pole
BOT
mode selector temperature
M5
connector 3-pole
c1
capacitor 1,5 μF for oven lamp 40W
m1
fan hot air main oven
c2
capacitor 1,5 μF for oven lamp 25W
m1t
fan hot air top oven
c4
interference filter
m2
fan cooling
D
hob connector 12-pole
m3
transformer halogen lamp
DS
door switch
m4
transformer timer
e1
door lock pyro
m5
transformer electronic
e11
distributor plate pot detection
m6
motor stirrer
E
hob connector 8-pole
m8
transformer high voltage
F
hob connector 21-pole
m12
turnspit motor
f1
thermostat temp -regulator main oven
m13
ignition coil gas
f1t (f1.1)
thermostat temp -regulator top oven
m20
cooling fan, L3
f2
safety term. limiter main oven
N1
electronic power board
f2t (f2.1)
safety term. limiter top oven
N2
module of induction
f3.1
thermostat steam generator 170°
N3
User interface
f3.2
thermostat steam generator 120°
N4
connector board
f5
thermostat cooling fan delay main oven
N5
PSU light bar (power supply unit)
f5t
thermostat cooling fan delay top oven
N6
light bar
f6
thermostat fast run cooling fan pyro
N7
electronic Smart
f7
sensor to magnetron
N8
touch input
f8
safety temp limiter bottom main oven
PE2
ground point bottom sheet f-oven
f9
LTC (Low Temp. Cooking) thermostat
PE3
ground point front frame left
f11
thermostat unlock pyro main oven
PE4
ground point front frame right
f11t
thermostat unlock pyro top oven
PE5
ground point bowl support front
f12
thermal switch cooling fan delay off (contact)
PE6
ground point bowl support rear
f15
2. safety temp. limiter oven
PE7
ground point hob frame
f16
thermostat overheating warning
PE8
ground point cavity main (only gas cooker)
f17
temperature sensor steam
PE1/b
ground point component plate main
f19
rack thermostat
PE1/bt
ground point component plate top
f21
safety temp. limiter grill
Q1
quick start module top oven
f22
safety temp. limiter fryer
r5
heating element steam generator
f31
residual contact front left
r6
top heating/grill combination
f32
residual contact rear left
r7
top heating element main oven
f33
residual contact rear right
r7 (r7.1)
top heating element top oven
f34
residual contact front right
r8
bottom heating element main oven
G1, G2
spark generator
r8t (r8.1)
bottom heating element top oven
G5
magnetron
r11
fat and smell filter
h1
lamp working
r12
thermal switch cooling fan delay off (heating)
h1t (h1.1)
lamp working top oven
r14
grill heating element main oven
h1.4
lamp working cooking zone front left
r14t (r14.1)
grill heating element top oven
h1.5
lamp working cooking zone rear left
r15
warming zone
h1.6
lamp working cooking zone rear right
r16
ring heating element main oven
h1.7
lamp working cooking zone front right
r16t
ring heating element top oven
h3
lamp heating main oven
r19
heating drawer
h3t (h3.1)
lamp heating top oven
r20
resistor cooling fan
h4
oven lamp main oven
r21
heater grill
h4t
oven lamp top oven
r22
heater fryer
h4.1
oven lamp side main oven
r27
resistor oven lamp
h4.6
lamp halogen
r27.1
resistor oven lamp side
h5
oven lamp top oven
r31
cooking zone front left
h5.1
oven lamp side top oven
r32
cooking zone rear left
h7
meat probe display
r33
cooking zone rear right
