Electrolux OVC3000 - Page 43

Technical Support - BSP 43/47 599 73 09-98 Rev. 02
Reference
Description
Reference
Description
r34
cooking zone front right
s23
sensor wok (middle)
r35
cooking zone middle
s31
ignition switch gas front left
s1
sensor pot detection front left
s32
ignition switch gas rear left
s2
sensor pot detection rear left
s33
ignition switch gas rear right
s3
sensor pot detection rear right
s34
ignition switch gas front right
s4
sensor pot detection front right
TR
telescopic runner switch main oven
s11
micro switch gas / electric
TRt
telescopic runner switch top oven
s12
micro switch grill / fryer
X1
main terminal
s13
micro switch grill socket
X10
tandem pin shells 6-pol.
s14
micro switch sensor
X11
tandem pin shells 8-pol.
s19
switch drawer
X12
connector hob
s21
sensor grill
x20
frame connector, L3
s22
sensor fryer
