Electrolux W3105H Service Manual

Service
Manual
23
23. Programme unit
38
438 9145-41/03
03.11
1 2 3
4 5 6
7 8 9
0
BUZZER ON BUTTON Y
MAX FILLING TIME 10:00
MAX HEATING TIME 10:00
SHOW WEIGHT TIMEOUT 0:20
PC5 BLOCKING OF HEATING N
PC5 BLOCKING OF SPINNING Y
HEAT 2 AS STANDARD Y
SERVICE ALARM HOURS Y
BUZZER TIMEOUT AT END Y
BUZZER TIMEOUT AT PAUS Y
ERROR, OVERFILLED Y
PASSWORD ACTIVE Y
CMIS ADDRESS 0
LEVEL IN MM ACTIVE Y
START SLOW FILLING, HG 10
OFFSET LEVEL, HG 2
READY
BUZZER ON BUTTON Y
MAX FILLING TIME 10:00
MAX HEATING TIME 10:00
SHOW WEIGHT TIMEOUT 0:20
PC5 BLOCKING OF HEATING N
PC5 BLOCKING OF SPINNING Y
HEAT 2 AS STANDARD Y
SERVICE ALARM HOURS Y
BUZZER TIMEOUT AT END Y
BUZZER TIMEOUT AT PAUS Y
ERROR, OVERFILLED Y
PASSWORD ACTIVE Y
CMIS ADDRESS 0
LEVEL IN MM ACTIVE Y
START SLOW FILLING, HG 10
OFFSET LEVEL, HG 2
READY
Y/N
Show weight timeout
Here you determine the length of time the weight
will be displayed, before the normal display is
restored.
Weight display
mode
CLARUS CONTROL
WEIGHT, KG:
007,0
PC5, Power Control
Here you determine whether input X15 on I/O PCB
1 (external pause signal) will have the ”external
pause signal” function (for this, the letter ”N” (No)
should be inserted on both option lines), or the
Power Control (PC5) function. For detailed
instructions on PC5 connection and settings, see
relevant manual section.
Use the numeric keys to
enter the value.
If you make a mistake while
entering digits:
Press ERASE.
When you have finished:
Press .
Answer Yes (Y) or No (N).
Press .
