23. Programme unit
438 9145-41/03
03.11
Y/N
Relay for steam as standard
Here you decide if the machine should heat with
steam or el. Yes (Y) the machine will heat with
steam (standard) and No (N) the machine will heat
with el.
SERVICE ALARM HOURS 0
1 2 3
4 5 6
7 8 9
0
Service interval
Here you determine the interval between service
interventions on the machine.
The statistics function of the programme unit
contains a counter that can be reset to show the
number of hours of effective washing on the
machine since the last service intervention.
TOTAL RUN TIME HOURS 0
0
HOURS SINCE LAST SERVICE 0
LAST 5 ERROR CODES PROGRAM HOURS
08 NO HEAT 991 0
08 NO HEAT 996 0
08 NO HEAT 993 0
08 NO HEAT 991 0
08 NO HEAT 991 0
STATISTICS
PROGRAM STEP: MAIN WASH 1
STEP TIME: 720 SEC
SET TEMPERATURE: 85 °C
ACTUAL TEMPERATURE: 21 °C
REMAINING TIME: 70 MIN
DRUM SPEED: 48 RPM
RAPID ADVANCE
PAUSE
991 NORMAL 95°C
S
When the service technician has serviced the
machine, this counter is reset.
When the time on the counter exceeds the
programmed interval, “S” is displayed in the lower,
left corner of the display indicating the need for
Service.
Answer Yes (Y) or No (N).
Press .
Use the numeric keys to
enter the value.
If you make a mistake while
entering digits:
Press ERASE.
When you have finished:
Press .
BUZZER ON BUTTON Y
MAX FILLING TIME 10:00
MAX HEATING TIME 10:00
SHOW WEIGHT TIMEOUT 0:20
PC5 BLOCKING OF HEATING N
PC5 BLOCKING OF SPINNING Y
HEAT 2 AS STANDARD Y
SERVICE ALARM HOURS Y
BUZZER TIMEOUT AT END Y
BUZZER TIMEOUT AT PAUS Y
ERROR, OVERFILLED Y
PASSWORD ACTIVE Y
CMIS ADDRESS 0
LEVEL IN MM ACTIVE Y
START SLOW FILLING, HG 10
OFFSET LEVEL, HG 2
READY
SELECT
READY
