Service
Manual
23
23. Programme unit
56
438 9145-41/03
03.11
DRAIN OPEN DELAY 0:13
START EXTRACT TIME 00:30
ROLLOUT TIME 00:01
PAY PER WASH ALARM 0
LOCK TEST DELAY 0:10
DRAIN TIME WHEN OVERFILL 0:05
OIL LUBRICATION HOURS 100
PULSE TIME OIL LUBR. SEC 0:01
AMOUNT OF I/O MODULES (1-3) 3
DELAY CLEAR DOOR TEXT 04:00
MAX DRAIN TIME 4:00
TIMEOUT DURING PAUSE 1:00
1 2 3
4 5 6
7 8 9
0
Time drain to open after over-filling
Here you determine how long the drain valve
should open for if the machine has over-filled,
provided you ensure that the parameter (response)
stored for the function ERROR OVER-FILLED is N
(No) (see below). The drain valve will open for the
time programmed and the level will then be
checked. If the level is still too high, the drain valve
will open again, and so on.
Over-filling can occur if a water valve is faulty, or if
you have over-filled the machine manually.
Also under ”SETTINGS 2” there are two functions
which influence the way the machine reacts to
over-filling:
ERROR OVER-FILLED
If you answer Y (Yes): if the drum becomes
over-filled, the machine will stop and the error
message ”MACHINE OVER-FILLED” will be
displayed.
If you answer N (No): the drain valve will open
as described above.
LEVEL OVERFILL (i.e. DRUM OVER-FILLED)
Here you specify the level at which the drum is
considered to be ”over-filled”.
Use the numeric keys to
enter the value.
If you make a mistake while
entering digits:
Press ERASE.
When you have finished:
Press .
