Service
Manual
23
23. Programme unit
58
438 9145-41/03
03.11
DRAIN TIME WHEN OVERFILL 0:05
OIL LUBRICATION HOURS 100
PULSE TIME OIL LUBR. SEC 0:01
AMOUNT OF I/O MODULES (1-3) 3
DELAY CLEAR DOOR TEXT 04:00
MAX DRAIN TIME 4:00
TIMEOUT DURING PAUSE 1:00
MINIMUM TEMPERATURE INCREASE 5°C
DOOR OPEN DELAY FOR MOTOR LOST 1:00
ERROR, NO WATER Y
ERROR, OPEN DOOR Y
ERROR, DOOR LOCK Y
ERROR, LOW TEMPERATURE Y
ERROR, HIGH TEMPERATURE Y
1 2 3
4 5 6
7 8 9
0
OIL LUBRICATION HOURS 100
PULSE TIME OIL LUBR. SEC 0:01
AMOUNT OF I/O MODULES (1-3) 3
DELAY CLEAR DOOR TEXT 04:00
TIMEOUT DRAIN AT PROGRAM START 4:00
TIMEOUT DURING PAUSE 1:00
MINIMUM TEMPERATURE INCREASE 5°C
DOOR OPEN DELAY FOR MOTOR LOST 1:00
ERROR, NO WATER Y
ERROR, OPEN DOOR Y
ERROR, DOOR LOCK Y
ERROR, LOW TEMPERATURE Y
ERROR, HIGH TEMPERATURE Y
ERROR, WATER IN MACHINE Y
1 2 3
4 5 6
7 8 9
0
Timeout drain at program start
If water in machine at wash program start, and
level not lower than emty level within given value,
an error will be indicated.
Delay clear door text
Here you determine how long the text ”WAITING
FOR DOOR TO UNLOCK” will remain visible if, for
some reason, the door is not unlocked at the right
time.
When a wash program has ended, the text above
will be displayed until the door is unlocked. The
door is normally unlocked within one minute on
most machines.
If the door is not unlocked within a reasonable
time, the most common cause is probably jamming
in the lock mechanism. In these cases, the text
above may mislead the user, causing him to think
that the normal unlocking sequence is not yet
finished.
Use the numeric keys to
enter the value.
If you make a mistake while
entering digits:
Press ERASE.
When you have finished:
Press .
Use the numeric keys to
enter the value.
If you make a mistake while
entering digits:
Press ERASE.
When you have finished:
Press .
