2. The User Interface
6
iConnect User Manual

Service Call Button
The Service Call button enables you to contact the monitoring service and talk
toanoperator.
Toinitiatea servicecall,press theuparrowbutton
,thenpressandholddownthe
ServiceCallbutton
.
Speed Dial
The Speed Dial  feature enables you to call from the control system up to five different
telephonenumbersprogrammedinthesystem–seep.34, 7.5SpeedDialNumbers.
To dial one of the programmed Speed Dial numbers, press the up arrow button
,
then press and hold down the number button 1 to 5 untilʺCall Spd # Dialingʺ is
displayed.Whenfinishedspeaking,pressthebuttontodisconnect.
Vocal Message Recording and Playback
LCDfront panelallows youtorecordashortmessagethatmaybeplayedbacklaterby
anotheruser–seep.35, 7.7.ServiceMenu,MessageCenter.
Home Automation and PGM On/Off Buttons
On
PressingoneoftheHomeAutomationbuttonsfollowedbythe
unit number (01‐16, or 30 for PGM) enables you to control
lights and appliances in your home, activate and deactivate
PGMoutput.
Pressing both Home Automation buttons simultaneously
generatesanSOSpanicalarm.
Off
System Status LEDs
The System Status indicators provide essential information on the status of the system
suchasarm,disarm,alarmandpowerfailureconditions.

OK LED Status
Meaning
Off Both AC and Battery power are disconnected.
On Green System Power status is OK and there is no System Trouble.
Flashing Green Open Zone. Check that the windows and doors are closed
and no movement is detected by the sensors within the
protected area.
On Yellow System Trouble.
Flashing Yellow (slow) Battery low from the Control System or transmitters.
Flashing Yellow (fast) AC loss.
Flashing Yellow
(intermittent)
System Trouble in addition to AC loss/Low Battery.
