2. The User Interface
iConnect User Manual
9
! LED Status
(Yellow)
Meaning
Off No trouble condition in the system.
On System Trouble.
Flashing
(slow)
Backup battery low or low battery from transmitters.
Flashing (fast) AC loss.
Flashing
(intermittent)
System Trouble in addition to AC loss/Low Battery.
, & LEDs
Meaning
Off The corresponding arming method is not active.
In partitioned systems, the corresponding
partition is disarmed. If all the three LEDs are
off, the system is disarmed.
Flashing Red The exit or entry delay for this arming mode is
counting down.
On Green The System is armed using the arming method
shown by this LED. In partitioned systems, the
corresponding partition/whole system is armed.
All the three Arm Status
LEDs flash Red
An alarm has occurred. Alarm indication is
cleared the next time you arm the system or
view the relevant event in the event log.
2.3. Alarm Sounding Patterns
Thefollowingtablesummarizesvariousalarmssoundedbythecontrolsystem.
Alarm Alarm Sounding Pattern Description
Burglary ON (continuously)
Fire ON - ON - ON, 1.5-second pause, ON - ON – ON......
Gas ON - ON - ON - ON (short bursts), 5 second pause, ON - ON -
ON - ON......
Medical ON (continuously) – only applicable for Medical alarm from zone
Flood 4 rapid tones sounded once per minute (same as Trouble tones)
Environmental 4 rapid tones sounded once per minute (same as Trouble tones)
