ADJUSTING THE FEET (B1 ITA= tranne il colore)
Place the machine on the work counter and ensure that it is level, by adjusting the length
of the feet.
Turn the black foot counter-clockwise, when viewed from underneath, to lengthen it and
clockwise to shorten it. There are no screws or nuts to be loosened or tightened.
WATER CONNECTION
The water is fed thanks to a connection with the drinkable water supply at a minimum
pressure of 0.15 MPa (1.5 bar) and a maximum pressure of 0.6 MPa (6 bar).
Hardness of the water not above 20°F.
Were the hardness higher than the above value, install a water softener between the water
network and the machine.
Should the water supply pressure exceed 0.6 MPa (6 bar), install a pressure reducer upline
of the coffee machine / water softener system.
An external check-valve may be required to meet local regulations.
The machine has a flexible steel-braided connection pipe with a 3/8 female connection,
approx. 1.7 metres in length.
1) Connect the flexible pipe to the coupling located on the bottom of the machine.
2) Connect this flexible tube to the water softener, if present, or directly to the water
network (water mains).
INSTALLATIONB
1
2
3 DRAIN CONNECTION (B7 =)
The machine has two rubber connecting pipes, one of 20 mm in external diameter
and the other of 18 mm in external diameter, both approx. 1.5 metres in length.
This flexible pipes must be made to flow into a fixed drain manifold with a minimum
internal diameter of 50 mm located underneath the machine work counter.
The space created by difference in diameter of the two pipes inserted into the drain
manifold must be left free for the venting of air during the discharging of the water.
1) Hook up the rubber pipe of 20 mm in diameter between the pipe fitting on the plastic
drain box installed at the bottom of the machine to the drain manifold located
underneath the counter, ensuring that it does not sag and that it is not strangled.
2) Hook up the rubber pipe of 18 mm in diameter between the metal pipe fitting
on the bottom of the machine to the drain manifold located underneath the counter,
ensuring that this too does not sag and that it is not strangled.
