APPENDIX B: MIDI IMPLEMENTATION
80
SYN2
Parameter CC MSB CC LSB NRPN MSB NRPN LSB
B Env Reset 88 1 22
Phase Reset 89 1 8
COMBINED
Parameter CC MSB CC LSB NRPN MSB NRPN LSB
Pitch All 1 23
Pitch 2 and 4 1 24
Ratio All 1 25
AB Level 1 26
AB Attack 1 27
AB Decay 1 28
AB End 1 29
AB Delay 1 30
B.4 FILTER PARAMETERS
FILTER
Parameter CC MSB CC LSB NRPN MSB NRPN LSB
Filter Frequency 23 55 1 20
Resonance 24 56 1 21
Filter Type 74 1 22
Attack Time 70 1 16
Decay Time 71 1 17
Sustain Level 72 1 18
Release Time 73 1 19
Env. Depth 77 1 23
Base 26 58
Width 27 59
B.5 AMP PARAMETERS
AMP
Parameter CC MSB CC LSB NRPN MSB NRPN LSB
Attack Time 104 1 24
Decay Time 105 1 25
Sustain Level 106 1 26
Release Time 107 1 27
Drive 9 41 1 28
Pan 10 42 1 30
Volume 7 39 1 31
Chorus Send 12 44 1
Delay Send 13 45 1
Reverb Send 14 46 1
Amp Env Reset 102 1
