APPENDIX B: MIDI IMPLEMENTATION
81
B.6 LFO PARAMETERS
LFO
Parameter CC MSB CC LSB NRPN MSB NRPN LSB
Speed LFO1 28 60 1 32
Multiplier LFO1 108 1 33
Fade In/Out LFO1 109 1 34
Destination LFO1 110 1 35
Waveform LFO1 111 1 36
Start Phase LFO1 112 1 37
Trig Mode LFO1 113 1 38
Depth LFO1 29 61 1 39
Speed LFO2 30 62 1 40
Multiplier LFO2 114 1 41
Fade In/Out LFO2 115 1 42
Destination LFO2 116 1 43
Waveform LFO2 117 1 44
Start Phase LFO2 118 1 45
Trig Mode LFO2 119 1 46
Depth LFO2 31 63 1 47
B.7 FX PARAMETERS
CHORUS
Parameter CC MSB CC LSB NRPN MSB NRPN LSB
Depth 3 35 2 0
Speed 9 41 2 1
High-pass 70 2 2
Width 71 2 3
Delay Send 12 44 2 4
Reverb Send 13 45 2 5
Mix Volume 14 2 6
DELAY
Parameter CC MSB CC LSB NRPN MSB NRPN LSB
Delay Time 15 47 2 10
Pingpong 16 48 2 11
Stereo Width 17 49 2 12
Feedback 18 50 2 13
Highpass Filter 72 2 14
Lowpass Filter 73 2 15
Reverb Send 19 51 2 16
Mix Volume 20 2 17
REVERB
Parameter CC MSB CC LSB NRPN MSB NRPN LSB
Predelay 21 53 2 20
Decay Time 74 2 21
