Note: Parameters CF37..CF41 have meaning only if the outputs have been configured as Triac outputs; The value to
enter represents the phase shift between voltage and current of the motor connected to the output (obtained from
cos indicated in the motor specifications).
The parameters for output AO2 are available only in models with this output.
Parameter CF34 ÷ CF35
Allow the Triac analogue output to be characterised in the following manner:
Value Description
0 Output configured as digital
1 Output configured as Triac (for pulse piloting)
Parameters CF37 ÷ CF38
Indicate the phase shift values of the pulse output (for adaptation to inductive load) and are active if CF34=1 and
CF35=1.
Parameters CF40 ÷ CF41
Indicate the duration of the pulse output (1 unit=69.4 μs) and are active if CF34=1 and CF35=1.
Parameters CF43 ÷ CF44
Indicate the logical meaning of the Triac analogue outputs and are active if CF34=1 and CF35=1.
