SERIAL CONFIGURATION
All models are fitted with 1 TTL serial channel for:
o Copy card connection to upload/download parameters.
o Serial communication with personal computer via RS-232/TTL conversion modules.
The TTL serial - referred to as COM1 - can be used for:
 configuring parameters with the ParamManager or DeviceManager software using the Eliwell protocol
 configuring parameters and monitoring with Televis Net software using the Eliwell or Modbus protocol PC
Interface connection modules are required.
 configuring device parameters, states, and variables with the Modbus via the Modbus protocol
For selection of the protocol and setting of the device address, see the following table:
Paramete
r
Description Value
CF54 Select COM1 (TTL) protocol 0 = Eliwell 1= Modbus
CF55 Eliwell protocol controller address
CF56 Eliwell protocol controller family
0…14
CF63 Modbus protocol controller address 1…255
CF64 Modbus protocol Baudrate
 0=1200 baud
 1=2400 baud
 2=4800 baud
 3=9600 baud
 4=19200 baud
 5=38400 baud
 6=58600 baud
 7=115200 baud
CF65 Modbus protocol parity
 1= EVEN
 2= NONE
 3= ODD
IMPORTANT: DO NOT supply power via TTL present on PC Interface 2150 to the EWCM4120-4150-4180 device.
To avoid errors, it is OBLIGATORY to cut the wire corresponding to 5Vdc of the 5-pole TTL connector, as illustrated
in the figure:
