Eliwell EWCM 4150 - Parameters List

61
PARAMETERS LIST
Note: When a parameter is edited outside of the limits, the display flashes. To stop the flashing, press the UP/DOWN
keys once. NOTE: CFBP = °C/°F/Bar/Psi
Par. Description Range
EWCM
4120
EWCM
4150
EWCM
4180
M.U.
CF Folder
CF02 Type of input analogue AI3 0…5 3 3 3 num
CF03 Type of input analogue AI4 0…5 3 3 3 num
CF04 Analogue input AI3 full scale value
CF05 Analogue input AI3 start of scale value
CF06 Analogue input AI4 full scale value
CF07 Analogue input AI4 start of scale value
Parameters CF04 … CF11 limit table
CF10 Analogue input AI3 differential
CF11 Analogue input AI4 differential
Parameters CF04 … CF11 limit table
CF14 Configuration of analogue input AI3 0…3 1 1 1 num
CF15 Configuration of analogue input AI4 0…3 0 0 2 num
CF16 Configuration of digital input DI1 -21…21 3 3 3 num
CF17 Configuration of digital input DI2 -21…21 4 4 4 num
CF18 Configuration of digital input DI3 -21…21 5 5 5 num
CF19 Configuration of digital input DI4 -21…21 6 6 6 num
CF20 Configuration of digital input DI5 -21…21 13 13 13 num
CF23
Configuration of analogue input AI1 when configured as
digital input
-21…21 1 0 1 num
