21
AL Er00 …. … … … Er99 Dynamic Alarms //
SP (1)* // // // // // set point(set) YES
Hr CP01 … CP04 Fn01 … Fn04 Dynamic
Operating hours
Compressors / fans
YES
SC CP01 … CP04 Compressor selection //
As you will be able to see from the table, the setpoint SP and time can be modified and viewed.
(1) * The following type is initially indicated for the set point: SUCTion Set, DISCharge Set. Press the "set" key once
again to view/edit the set point value.
Programming menu
Menu Folder Subfolders Description
Parameters PAr CF Ui St CP Fn AL Pass CC OP Parameters
EU EU Eu00 … … … … … … … Eu99 Alarms log
EUR EUR Reset alarm history
CONFIGURING THE MACHINE
1) ANALOGUE INPUTS (AI3, AI4)
The device has 2 analogue inputs which are configurable using the following parameters:
CF02* Type of analogue AI3 input CF07 Analogue AI4 input start of scale value
CF03* Type of analogue AI4 input CF10 Analogue AI3 input differential
CF04 Analogue AI3 input end of scale value CF11 Analogue AI4 input differential
CF05 Analogue AI3 input start of scale value CF14** Configuration of analogue AI3 input
CF06 Analogue AI4 input end of scale value CF15** Configuration of analogue AI4 input
See Parameters F04 … CF11 limits table
