Parameter CF42
Indicate the logical meaning of Triac analogue outputs. It is possible to pilot loads with output modulation
(value 25-26) or loads with on/off type switching using the Triac as a switch. For meaning see table entitled
Configuration of Parameters CF43 ÷ CF44 in PWM/OPEN COLLECTOR OUTPUTS AO1 and AO2.
6) LOW VOLTAGE ANALOGUE AO3 OUTPUT
In certain models, the device has 1 low voltage analogue output configurable by means of the user parameters.
Depending on the application, the output may be available as 0-10V or 4-20mA
AO3 configuration
Parameter Description M.U. Min Max
CF27 Type of output analogue AO3 num 0 2
CF30 Configuration of analogue output AO3 num -24 26
Parameter CF27
Allows the Triac analogue output AO3 to be characterised in the following manner:
Value Type Description Notes
0 0-10V Analogue output - voltage Modulated piloting or on/off
1 4-20mA Analogue output - current Modulated piloting or on/off
2 0-20mA Analogue output - current Modulated piloting or on/off
Parameter CF30
Indicates the logical meaning of the analogue output. It is possible to pilot loads with output modulation
(value 25-26) or loads with on/off type switching using the output as switch 0-10V. For meaning see table
entitled Configuration of Parameters CF43 ÷ CF44 in PWM/OPEN COLLECTOR OUTPUTS AO1 AND AO2.
