15
The maximum zoom ration is 16x (digital zoom).
The image quality will be degraded when using the digital
zoom.
USING THE PRODUCT
ADJUSTING THE SIZE
The size of the image can be adjusted using [ / ]
buttons on the operating panel.
ADJUSTING THE BRIGHTNESS
The brightness of the image can be adjusted using [ / ] buttons on the operating
panel. The brightness does not change automatically according to the brightness of the
shooting environment.
To initialize the brightness level, press these buttons at the same time.
ADJUSTING THE FOCUS
Press [ ] on the operating panel to automatically focus on the subject.
PAUSING THE IMAGE
Press [ ] on the operating panel to pause the camera image.
Press the button again to restart.
The Status LED flashes yellow when the camera image is paused while the power is
supplied with the AC adapter.
ROTATING THE IMAGE
Press [ ] on the operating panel to rotate the image by 180°.
TURNING THE LED LIGHTING ON/OFF
Press [ ] on the operating panel to ON/OFF the LED lighting.
NOTE
CAUTION
To take shots of people, turn the LED lighting OFF.
Make sure that the light from the LED lighting does not shine directly into your eyes.
This product is equipped with a high-brightness LED. You can safely use it to light
up the object. The brightness will gradually decrease with long-term use. This is
not a malfunction but a characteristic of the LED.
Do not touch the LED lighting while it is on as it may become very hot.

Other manuals for Elmo MX-P

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Elmo MX-P and is the answer not in the manual?

Elmo MX-P Specifications

General IconGeneral
Auto focusYes
Digital zoom16 x
Shooting area (WxD)373.3 x 281.9 mm
Lamp typeLED
Product colorWhite
Sensor type-
Maximum frame rate60 fps
Optical sensor size- \
Supported graphics resolutions1920 x 1080 (HD 1080), 3840 x 2160
InterfaceUSB 3.2 Gen 1 (3.1 Gen 1)
USB connector typeMicro-USB B
VGA (D-Sub) output ports1
Operating voltage5 V
Power supply typeDC
Power consumption (typical)4.6 W
Weight and Dimensions IconWeight and Dimensions
Depth81.2 mm
Width324.9 mm
Height302 mm
Weight544 g
Dimensions folded (WxDxH)289.5 x 81.2 x 22.8 mm
