SPECIFICATION
MAIN CAMERA
Item
Specifications
Power source
DC5V
Power consumption
3.2Wwhen connecting USB
4.6Wwhen connecting HDMI/RGB
Outside dimensions
W343mm D82mm H302mm(When setup)
W290mm D82mm H22mm(When folded)
Weight
Approx. 550gMain body only
Ext. control terminal
USB3.0 type microB × 1
Lens
F=2.0
Frame rate
60fpsin high frame rate mode at 1080P
Focus working range
From lens surface100mm
Focus
AutoOne-push
Exposure
Auto (Possible to adjust exposure level)
Image pick-up
element
1/3.1 inch CMOS 13,000,000 pixels
Effective pixels
H: 4160, V: 3120
Resolution
H: 1300TVlines or more V: 1300TVlines or more
Digital zoom
Max. 16x (when outputting HDMI/RGB)
Imaging area
374mm×281mmHeight286mm 43
FUNCTIONAL SPECIFICATION
Item
Content
Operation
panel
IM4
Brightness
Possible (Set value 7 levels) Default value: 8
Image rotation
0°/180° Default setting: 0°
The image rotation function is not available when the
image freeze function is used.
LED lighting
ON/OFF Default setting: OFF
AFfocus
ManualOne-push
Zoom
Possible
Video still
Possible
Resolution
Manual
Flicker
60Hz / 50HzDefault setting: 60Hz
USB: select with IM4
HDMI/RGB: select with the Slide switch
Contrast
PossibleSet value 020 Default value: 12
