Elmo MX-P User Manual

7
➊ PREPARATION
◆PACKAGE CONTENTS
The items below are included with this product. If any item is missing, contact the
dealer from whom you purchased this product.
DC power cord
USB3.0 cable
Quick Start Guide
Warranty Card
(For Japan/ North
America only）
AC adapter
CAUTION
・Do not wrap the power cable tightly around the AC
adapter while the power cable is connected to the AC
adapter. The cable could be damaged (disconnected)
or the inside of the cable could be exposed and result
in an accident.
MX-P
(For Japan/ North
America only)
(For Europe only)
(For Australia only)
●Only Europe and Australia
Press and slide the plug into the groove of the AC adapter
as shown in the drawing.
※Slide it until it clicks.
※Choose the correct plug accordingto the outlet.
When removing the plug from the AC adapter, slide and pull
the plug in the opposite direction while pressing the lock button.
Click!

Elmo MX-P Specifications

General

Auto focus	Yes
Digital zoom	16 x
Shooting area (WxD)	373.3 x 281.9 mm
Lamp type	LED
Product color	White
Sensor type	-
Maximum frame rate	60 fps
Optical sensor size	- \
Supported graphics resolutions	1920 x 1080 (HD 1080), 3840 x 2160
Interface	USB 3.2 Gen 1 (3.1 Gen 1)
USB connector type	Micro-USB B
VGA (D-Sub) output ports	1
Operating voltage	5 V
Power supply type	DC
Power consumption (typical)	4.6 W

Weight and Dimensions

Depth	81.2 mm
Width	324.9 mm
Height	302 mm
Weight	544 g
Dimensions folded (WxDxH)	289.5 x 81.2 x 22.8 mm
