D. MACHINE FRAME
Case Step Point Remark
Film jumping Claw
(P4-40)
If the tip of Claw has been worn or inclined,
adjust the position of Claw against the film
perforation.
Pressure plate assy
(P3-40)
If Pressure plate assy has been deformed or
tilted unevenly, replace or adjust the position.
P-7
If the spring pressure of Pressure plate is
insufficient, replace Pressure plate spring.
Cam shaft
(P4-27)
If the uneven end-play of Cam shaft has been
developed due to wearing, replace Cam assy.
P-13
Film guide 2
(P3- 37)
If the film is held excessively between Film
guide 1 and 2, adjust the position of Film guide
2.
Picture flow Shutter assy
(P4-28)
To complete the synchronization between
Shutter assy and Claw, adjust the, position of
Shutter.
Film flow Claw
(P4-40)
If the tip of Claw has been broken or the stroke
of Claw is insufficient with respect to the film
perforation pitch, replace Claw.
If the tip of Claw could not protrude far enough
above Aperture plate assy or is not in
perforation during feeding, adjust the position
of Claw.
Film Check the film perforations whether
has been damaged.
Upper film loop is
gradually
illuminated
First sprocket shoe
assy
(P3-30)
Replace Shoe mount spring 2 to obtain
sufficient pressure.
P-14
Lower film loop is
gradually
illuminated
Sprocket presser
(p5-30)
Replace Lock lever spring to obtain sufficient
pressure.
- to be continued -
