MACHINE FRAME (Cont'd)
Case Step Point Remark
Auto-threading
mechanism cannot
be released
Solenoid lever
(P4-32)
Adjust the position of Solenoid lever so that
Loop former lever assy may be released.
P-13
Film loop moves to
upper side
Lateral guide 1,2
(P3-35)
Increase the spring tension of lateral guide
spring to prevent the movement of film loop.
Slide plate
(P3- 39)
Bend Slide plate upward to prevent the
movement of film loop.
Lower film loop
cannot be performed
Fly wheel
(P5-24)
Increase the spring tension of Fly wheel spring.
Pad roller
(P5-64)
Adjust the position of Link lever spring so that
the tension of Pad roller may be increased.
P-16
Tension roller
(P5-63)
Move the position of Balance lever spring so
that the film may not be stretched downward
excessively.
P-16
Motor switch knob
cannot be turned
Reverse lever
(P6-20)
If Reverse lever has been interrupted and
deformed by AMP holder 2, replace or fix
Reverse lever and also cut off the portion of
AMP holder 2 to not interrupt the movement of
Reverse lever.
P-12
Film has been
feeded during still
projection
Clutch
mechanism
(P7-8)
Adjust the position of Clutch lever (1) assy, at
the same time, adjust the position of Clutch
link adjuster as well as Clutch lever (2) assy to
convey the rotation of Motor assy during both
18 f/s and 24 f/s projection.
P-10
- 25 -
