ELNA 6004 - Top Cover and Face Plate; Top Cover; Face Plate

Elna International Corps. SA 6004 Service manual
TOP COVER AND FACE PLATE
TOP COVER
1
To remove :
2 Remove the tree set screws A and B and the Top cover.
3
To attach :
4 Attach the top cover with the tree screws A and B
FACE PLATE
1.
To remove :
2. Remove the two set screws C and face plate
3.
To attach
4. Attach the face plate with two set screws C.
Page 01
