ELNA 6004 - Base and Bed Cover; Base; Bed Cover

Elna International Corps. SA 6004 Service manual
BASE AND BED COVER
BASE
1
To remove :
2 Remove six set screws A and base.
3
To attach :
4 Attach the bsase with six set screws A
BED COVER
1
To remove :
2 Move the fed drop lever to the left, then remove the two set screws B.
3 Remove the bed cover
4
To attach
5 Move the feed drop lever to the left and attach the bed cover with two set screws B.
Page 02
