ELNA CE10 - Adjusting Needle Thread Tension

14
Adjusting Needle Thread Tension
The standard of upper thread tension should be 51 g to 59g when pulling the thread
(cotton thread #50) in the direction of A when
1 Set the Thread tension dial at “3”.
2Lower the presser foot.
3 Remove the front cover unit and adjust the thread
tension.
(A) If the thread tension is 59g or more
.................turn the screw in the direction of “B”.
(B) If the thread tension is 51 g or less
...............turn the screw in the direction of “A”
Pull the #50 cotton thread in the direction
of the arrow. (Pulling speed 110 mm/ Sec.)
(A)
(B)
1
1
