23
Adjusting Slide Volume
To adjust the solenoid, follow the instructions below.
1. Remove the front cover. (See page 6)
2. Loosen Screws (2 pieces).
3. Lower the presser foot lifter and adjust the Clearance
between the Discs while the discs are closed.
4. Tighten Screws .
1
2
3
4
Screw (A)
Discs
Clearance (aproximately 1.6 mm)
Plunger
Slide to the right side.
5
1
1
2
3
1
2
3
4
5
