ELTEX MES53xx User Manual

MES53xx, MES33xx, MES23xx Ethernet Switch Series 194
area A.B.C.D nssa


interval] [translator-role
{always | candidate}]
A.B.C.D: router ID in the
IPv4 address format;
interval: positive integer;
Set the NSSA type for the specified area.
- no-summary - do not accept information about external
summary routes inside the NSSA area;
- interval  set the time interval (in seconds) during which
the translator will continue to operate after detecting that
another edge router became a translator.
- translator-role - set the translator mode on the router
(translation Type-7 LSA to Type-5 LSA):
- always - constant forced mode;
- candidate - participation in translation selection mode.
no area A.B.C.D nssa
Set the default value.
area A.B.C.D virtual-link
A.B.C.D [hello-interval secs]
[retransmit-interval secs]
[transmit-delay secs]
secs] [null |
message-digest] [key-chain
word]
A.B.C.D: router ID in IPv4
address format;
Secs: (1..65535) seconds;
word: (1..256) characters
Create virtual connection from the main area to other
remote areas for which there are areas in between.
- hello-interval - set the hello interval;
- retransmit-interval - set the interval between repeated
transmission;
- transmit-delay - set the delay;
- dead-interval - set the dead interval;
- null - without authentication;
- message-digest - authentication with encryption;
- word - password for authentication.
no area A.B.C.D virtual-link
A.B.C.D [hello-interval secs]
[retransmit-interval secs]
[transmit-delay secs]
secs] [null |
message-digest] [key-chain
word]
Delete a virtual connection.
area A.B.C.D default-cost cost
A.B.C.D: router ID in the
IPv4 address format;
cost: positive integer
Set the cost of a summary route used for stub and NSSA
areas (for IPv4).
no area A.B.C.D default-cost
Set the default value.
area A.B.C.D authentication
[message-digest]
A.B.C.D: router ID in the
IPv4 address format;
-/disabled
Enable authentication for all interfaces for a given area (for
IPv4):
- message-digest - with MD5 encryption.
no area A.B.C.D
authentication

Disable authentication.
area A.B.C.D range
network_address mask
[advertise | not-advertise]
A.B.C.D: router ID in the
IPv4 address format;
network_address: A.B.C.D
mask: E.F.G.H
Create summary route on the area boundary (for IPv4).
- advertise - announce the created route;
- not-advertise - do not announce the created route.
no area A.B.C.D range
network_address mask
Delete a summary route.
area A.B.C.D filter-list prefix
prefix_list in
A.B.C.D: router ID in the
IPv4 address format;
prefix_list: (1..32)
characters
Set a filter that applies to routes announced to the specified
area from other areas (for IPv4).
no area A.B.C.D filter-list
prefix prefix_list in
Remove a filter that applies to routes announced to the
specified area from other areas (for IPv4).
area A.B.C.D filter-list prefix
prefix_list out
A.B.C.D: router ID in the
IPv4 address format;
prefix_list: (1..32)
characters
Set a filter that applies to routes announced from the
specified area to other areas (for IPv4).
no area A.B.C.D filter-list
prefix prefix_list out
Remove a filter that applies to routes announced from the
specified area to other areas (for IPv4).
area A.B.C.D shutdown
A.B.C.D: router ID in the
IPv4 address format;
-/enabled
Disable an OSPF process for an area.
no area A.B.C.D shutdown
Enable an OSPF process for an area.
shutdown
-/enabled
Disable an OSPF process.
no shutdown
Enable an OSPF process.
IP interface configuration mode commands
Command line prompt is as follows:
console(config-ip)#
