MES53xx, MES33xx, MES23xx Ethernet Switch Series 58
– te_port – sequential number of 10G interfaces specified as follows: 1..8/0/1.. 4;
– gi_port – sequential number of 1G interfaces specified as follows: 1..8/0/1..24;
– loopback_id – sequential number of a virtual interface corresponding Table
(‘Number of virtual Loopback interfaces’ string).
For MES2348B
Table 5.30 – List of interface selection commands for MES2348B
interface tengigabitethernet te_port
For configuring 10G interfaces
interface gigabitethernet gi_port
For configuring 1G interfaces
interfaceport-channelgroup
For configuring channel groups
interface loopback loopback_id
For configuring virtual interfaces
Where
– group – sequential number of a group, total number in accordance with Table 2.9. Main
specifications (‘Link agregation (LAG)’ string);
– te_port – sequential number of 10G interface specified as follows: 1..8/0/1.. 4;
– gi_port – sequential number of 1G interface specified as follows: 1..8/0/1..48;
– loopback_id – sequential number of virtual interface corresponding Table 2.9. Main specifications
(‘Number of virtual Loopback interfaces’ string).
For MES2308 and MES2308P
Table 5.31– List of interface selection commands for MES2308, 2308P
interface gigabitethernet gi_port
For configuring 1G interfaces
interfaceport-channel group
For configuring channel groups
interface loopback loopback_id
For configuring virtual interfaces
where
– group – sequential number of a group, total number in accordance with Table 2.9. Main
specifications (‘Link agregation (LAG)’ string);
– gi_port – sequential number of 1G interface specified as follows: 1..8/0/1..12;
loopback_id – sequential number of virtual interface corresponding to Table 2.9. Main
specifications (‘Number of virtual Loopback interfaces’ string.
Interface entry
1..8/0/1..N
number of the stack unit slot number interface number
Commands entered in the interface configuration mode are applied to the selected interface.
